Zee’s Customs Inc. offers the brightest L.E.D. replacement headlamps for your: Streetglide, Ultra Classic, Roadking, Softail, Sportster, Vrod, and Roadglide.  These headlamps were designed to out perform any factory or aftermarket headlamp on the market.  We have addressed the common issues with a excellent beam pattern. With all of our lights you get a quality product, a safer riding experience, and great price.

Zee's_011616_LOGO

Zee's_011616_LOGO2Z L.E.D. Roadglide Headlamp-Bezel 489.00 available in black or chrome 2004-2013 (will fit 2000-2003 with minor modifications)

Z L.E.D. Headlamp Lens Finish :
 Includes: headlamp assy, bezel, reinforcement bracket, and hardware. (chrome headlamp includes chrome bezel, black headlamp includes black bezel.)  COMPLETE PLUG AND PLAY INSTALLATION!

Ask for painted to match bezels,offering HD & custom colors for an additional cost..

General Specifications
Z L.E.D. Roadglide Headlamp-Bezel
Lens Pattern : High & Low Beam
Lens Material : Hardcoated Polycarbonate Available: In Black or Chrome
Housing Material : Die-Cast Aluminum
Fitment: 2004-2013 Harley Davidson Roadglide (1998-2003 some modifications required)
Thermal Protection Safeguard
Rugged Solid State L.E.D.’s
Connector:Dual H4 (Ground and High Beam)
Color Temp. 6000k
Weight: 3.95 lbs

One Year Warranty

Technical Specifications
Z L.E.D. Headlamp
12 volt: 4.00 Amps (High Beam); 2.50 Amps (Low Beam)
Raw Lumen Output: 4240LM(High Beam), 2820LM(Low Beam)

Effective Lumen Output: 3392LM(High Beam),2256LM(Low Beam)





Zee's_superwater



Zee'sSGCwater

Z L.E.D. Super Headlamp 369.00 available in chrome or black



Z L.E.D. Headlamp Lens Finish :
Model :
Year :


(Note for 2014+ you will need a headlamp adapter harness 2014-17 HD P/N 69200897 which is below)  COMPLETE PLUG AND PLAY INSTALLATION!  Be sure to check of the new FLARE bezels for your Streetglide- Ultra Classic- Roadking

Fits ’12-later FLD, ’94-’17 Touring (except Road Glide®) and ’09-’13 Trike models. Also fits ’94-later Softail® models equipped with Freight Train Headlamp Nacelle Kit. ’06-’10

ZEE_LEDH_L

Here’s an accurate view of our Z L.E.D. Super Headlamp.  Our test range was 78′ wide and the motorcycle was 90′ back from the building where the beam was cast. Notice the full beam pattern from right to left illuminating the sidewalks and shoulders, this pattern starts from the bike and angles outward “on the ground” filling any empty voids!. Also note the intense low and high beam, our headlamps are unlike any other on the market, taking care of all of the dark areas for a awesome and most importantly a SAFER riding experience

BLACK_MAIN_PASS_LOGO CHROME_MAIN_PASS_LOGO


Z L.E.D. Super Headlamp-Passing Lamp Package 600.00  available in chrome or black

Z L.E.D. Headlamp-Passing Lamp Package Lens Finish :
Model :
Year :


(Note for 2014+ you will need a headlamp adapter harness 2014-17 HD P/N 69200897 which is below)

Our new Z L.E.D. Headlamp-Passing Lamps blows the competition away.  We have designed a headlamp that is 30-40 percent brighter than anything on the market! These lights offer a great beam pattern along with flood too, this will help illuminate the sides of the roads for a great riding experience.  Available in Chrome or Black. Backed up with a one year warranty. Super Headlamp includes a new mounting bracket with a trim ring for a simple installation. (2014-16 requires HD  P/N 69200897 adapter which is not included)

General Specifications
Z L.E.D. Headlamp
Lens Pattern : High & Low Beam
Lens Material : Hardcoated Polycarbonate Available: In Chrome or Black
Housing Material : Die-Cast Aluminum
Fitment: 1998-2017 Harley Davidson Batwing Fairing
Thermal Protection Safeguard
Rugged Solid State L.E.D.’s
Connector: H4 (Ground and High Beam)
Color Temp. 6000k
Weight: 2.53 lbs

Technical Specifications
Z L.E.D. Headlamp
12 volt: 4.00 Amps (High Beam); 2.50 Amps (Low Beam)
Raw Lumen Output: 4490LM(High Beam), 2830LM(Low Beam)

Effective Lumen Output: 2670LM(High Beam),1680LM(Low Beam)


14-16 adapterZ L.E.D. Headlamp adapter harness 2014-17 HD P/N 69200897 $16.00



PhotoGrid_1422641801319

Z L.E.D. Halo Headlamp 329.00 on sale 296.10 Chrome or Black Available Halo Colors: Red.Green.Blue.White

Z L.E.D. Halo Headlamp Color :
Year :



Z L.E.D. Halo Headlamp Passing Lamp Package 560.00 on sale 504.00 Chrome or Black Available Halo Colors: Red.Green.Blue.White

Z L.E.D. Halo Headlamp Color :
Year :
Year :


Fits ’12-later FLD, ’94-’17 Touring (except Road Glide®) and ’09-’17 Trike models. Also fits ’94-later Softail® models equipped with Freight Train Headlamp Nacelle Kit. ’06-’10

(2-3 days for shipping) *Passing Lamps Do Not Include Halo’s* (2014-17 requires HD  P/N 69200897 adapter which is not included)

Z L.E.D. Halo headlamp
General Specifications
Lens Pattern : High & Low Beam
Lens Material : Hardcoated Polycarbonate Available:Black Or Chrome Reflector
Housing Material : Die-Cast Aluminum
Fitment: 1998-2017 Harley Davidson Batwing Fairing
Halo color options: Red, Green, Blue, White (White can be used as a day time running lamp)
Rugged Solid State L.E.D.’s
Connector: H4 (Ground and High Beam)
Color Temp. 6000k
Weight: 2.42 lbs

Technical Specifications
Z L.E.D. Halo Headlamp
12-14V DC Input
12 volt: 3.0 Amps (High Beam); 2.5 Amps (Low Beam)
Raw Lumen Output: 2600LM(High Beam), 1700(Low Beam)

Effective Lumen Output: 1602LM(High Beam), 1020LM(Low Beam)



PhotoGrid_1434901973071 Headlamp Mounting Bracket 30.00





Headlamp mounting bracket, if you do not choose to cut open your stock mounting bracket these are a perfect fit.  *** FYI these are included with the Super and Halo headlamps***

Fitment:1998-2017 batwing fairing bikes,softails and roadkings.



Z L.E.D. Black Passing Lamp 289.00 pair
Z L.E.D. Black Passing Lamp 249.00 pair
passing lampchrome
Z L.E.D. Chrome Passing Lamp 249.00 pair



Z L.E.D. Passing lamp Lens Finish :
Year :


(2-3 days for shipping)

Z L.E.D. Passing Lamps
Lens Material : Hardcoated Polycarbonate Available:Black Or Chrome Reflector
Housing Material : Die-Cast Aluminum
Fitment: 1998-2016 Harley Davidson
Thermal Protection Safeguard
Rugged Solid State L.E.D.’s
Color Temp. 6000k
Weight: 2.00 lbs
Technical Specifications
Z L.E.D. Headlamp
12-14V DC Input
12 volt: 2.25 Amps
Raw Lumen Output: 1440LM.   Effective Lumen Output: 840LM

Fits models with a 4″ round auxiliary forward lighting



Halo Passing lamps

Halo Passing Lamps 259.00 on sale 233.10 **Amber coming soon! (to run as turnsignals)

Z L.E.D. Passing lamp Lens Finish :
Halo Color :


Fits models with a 4″ round auxiliary forward lighting



ZLED_Chrome_5.75_LOGO

ZLED_BLACK_5.75_LOGO

Z L.E.D. 5.75″ Super Headlamp (sportster-dyna-softail-custom-select Vrods) 179.00 available in chrome or black

Z L.E.D. Headlamp Lens Finish :


Fitment: Fits ’06-’11 VRSCD and VRSCDX, ’15-later XG, ’04-later XL, ’09-’13 XR, ’91-later Dyna® (except FLD and ’91-’05 FXDWG), ’84-’99 FLSTS and FXSTS, ’08-’11 FLSTSB, ’05-’06 FLSTSC, ’10-12 FLSTSE, ’00-later FXCW, FXCWC, FXS, FXSB, FXSBSE, FXST, FXSTB, FXSTC and FXSTD models. Some models require Vibration Damper or Housing Kit

Z L.E.D. 5.75″ Headlamp
Lens Material : Hardcoated Polycarbonate Available:Black Or Chrome Reflector
Housing Material : Die-Cast Aluminum
Thermal Protection Safeguard
Rugged Solid State L.E.D.’s
Color Temp. 6000k
Weight: 1.5 lbs
Technical Specifications
Z L.E.D. Headlamp
12-14V DC Input
12 volt: 2.25 Amps
Highbeam  Output: 4100LM.   Lowbeam Output: 2890LM



The Flare bezel adds just enough attitude to your bike to set it aside from all of the others out there. It installs in just a few minutes, remove you existing bezel and install your new Flare bezel in its place. Available in satin black $65.00 ea.  *note this is NOT a slip over

zee_flare_blk

zee_flare_chr2

zee_flare_chr

“The Flare Bezel satin black” 65.00

This item is currently on back order

Fitment: ’12-later FLD, ’94-’13 Touring (except Road Glide®). Also fits ’94-later Softail® models equipped with Freight Train Headlamp Nacelle Kit. ’06-’10



Any return for a refund may be subject to a 20% restocking fee. This fee may be waived for the following reasons:

  • Carrier damage
  • Defective product

giftcardforwebsite

Purchase a gift card for that “hard to buy for person”  sold in 100.00 increments, purchase as many as you need.  The gift cards can be used for any products on or off the website.

–Order our ” Zee’s Customs Gift Card ” 100.00



Streamline Headlamp 299.00 available in chrome or black

Streamline Headlamp Lens Finish :
Year :
